A State of
Compile Time Regular Expressions

Hana Dusíková

Researcher in Avast
- Making things around me better
Avast Prague C++ Meetup
Czech National Body in WG21

Occasional hiker
Enthusiastic photographer
Owns a pet sequoia and greyhound

@hankadusikova

#ctre #cpppfr

`std::regex`

A story of one `std::regex`


						struct date {
							std::string year;
							std::string month;
							std::string day;
						};

						std::optional<date> extract_date(std::string_view input) noexcept {
							static std::regex pattern("([0-9]{4})/([0-9]{2})/([0-9]{2})");

							std::smatch_results<std::string_view::iterator> captures;

							if (!std::regex_match(input.begin(), input.end(), captures, pattern)) {
								return std::nullopt;
							}

							return date{
								captures[1].str(),
								captures[2].str(),
								captures[3].str()
							};
						}

And it takes only 1.3 sec to compile…

Introducing
The Compile Time Regular Expressions
Library

A Story of one regex reimagined


							struct date {
								std::string year;
								std::string month;
								std::string day;
							};

							std::optional<date> extract_date(std::string_view input) noexcept {
								auto [match, y, m, d] = ctre::match<"([0-9]{4})/([0-9]{2})/([0-9]{2})">(input);

								if (!match) {
									return std::nullopt;
								}

								return date{y.str(), m.str(), d.str()};
							}

Error Reporting


						bool fnc(std::string_view view) {
							return ctre::match<"(hello">(view);
						}


						In file included from test.cpp:1:
						In file included from include/ctre.hpp:5:
						include/ctre/functions.hpp:48:2: error: static_assert failed due to requirement 'correct' "Regular Expression contains syntax error."
						        static_assert(correct, "Regular Expression contains syntax error.");
						        ^             ~~~~~~~
						test.cpp:2:15: note: in instantiation of function template specialization 'ctre::match<"(hello">' requested here
						        return ctre::match<"(hello">(view);
						                     ^

Example: Extracting a value


							std::optional<std::string_view> extract_sha256(std::string_view input) noexcept {
								if (auto r = ctre::match<"[a-fA-F0-9]{64}">(input)) {
									return r;
								} else {
									return std::nullopt;
								}
							}

Example: Iterate over
concatenated sequence of numbers


							int sum(std::string_view input) {
								int output = 0;
								for (const auto & capt: ctre::range<"^,?([0-9]+)">(input))
									output += to_integer(capt.get<1>());
								return output;
							}

Example: Unicode Support (🌈🦄🥰)


							constexpr bool is_emoji_only(std::u32string_view input) noexcept {
								return ctre::match<"\\p{emoji}+">(input);
							}


							  static_assert( is_emoji_only(U"🤪🤡🥳"));
							  static_assert(!is_emoji_only(U"💩java"));

*unicode support is not yet fully merged

**thanks to Corentin Jabot for providing constexpr unicode tables ❤️

Example: DFA matching / searching


							bool contains_date(std::string_view input) noexcept {
								return ctre::fast_search<"[0-9]{4}/[0-9]{2}/[0-9]{2}">(input);
							}

Features of CTRE

PCRE2 compatible dialect
- basic unicode support
- optimizing greedy cycles into possessive if possible
constexpr
- compile time constructing
- constexpr & runtime matching
- doesn't support runtime defined patterns
quick regex matching/searching
- structured-bindings for extracting captures
- DFA matching without captures
- generates compact assembly

Technical details of CTRE

small, header only C++17/20 library (8k LoC)
supports all major compilers
- clang 6.0
- gcc 7.4
- msvc 15.8.8+
open-source
- apache-2.0 license
- available on github.com

Regular Expressions

`hello|aloha|guten tag|dobrý den|bonjour`

`[a-z]+[0-9]+`

A Regular Expression is (formally)

the empty set (∅ or {}),
an empty string (ε or {""}),
a literal character (e.g. a or {"a"}),

the concatenation of two REs (A⋅B),
the alternation of two REs (A|B),
or repetitions (Kleene star) (A*)

Non-formal syntax constructs

Optional A (A? is ε|A)
Plus repetition of A (A⋅A*)
Back-reference

not all features of a "regular expression"
implementation is technically a regular expression

Example: Non-formal syntax constructs

We are all used to a pattern like this:
(ct)?re|[a-f]+

The pattern is equivalent to:
(ε|ct)re|(a|b|c|d|e|f)(a|b|c|d|e|f)*

Every pattern can be converted into a formal form.

A Regular Expression
can be described as an abstract syntax tree

(ct)?re|[a-f]+

How to store the AST
in C++ compile-time evaluated code?

tree-like (allocated) data structure (we can't allocate in constexpr, yet)
type based expression
- expression templates (like boost::xpressive)
- tuple-like empty types

Types as the building blocks


							// building blocks
							struct epsilon { };
							template <Character auto C> struct ch { };

							// operations
							template <typename...> struct concat { };
							template <typename...> struct alt { };
							template <typename> struct star { };

							// for convenient usage
							template <typename E> using opt = alternation<E, epsilon>;
							template <typename E> using plus = concat<E, star<E>>;

Example: A Regex Type

Converting
A pattern into an AST: Parsing

How to convert the pattern?

Use a generic LL(1) parser for converting a pattern into a type.
The parser uses a provided PCRE compatible grammar.
Output type is the AST.

How does an LL(1) parser work?

Starts with a start symbol on the stack.
On every step it pops one symbol from the stack
and checks the current character at the input.
Based on the pair of symbol and character it decides to:
- push a string of symbols to the stack,
- pop a character from the input,
- or reject.
Repeat until the stack and input are empty then accept.

What does the grammar look like?

f(symbol,char) → (...) ε pop input reject accept

	(	)	*	+	?	\|	other	ε
→ S	( alt0 ) mod seq alt						other char mod seq alt	ε
alt0	( alt0 ) mod seq alt						other char mod seq alt
alt		ε				\| seq0 alt alt		ε
mod	ε	ε	* star	+ plus	? opt	ε	ε	ε
seq0	( alt0 ) mod seq						other char mod seq
seq	( alt0 ) mod seq seq	ε				ε	other char mod seq seq	ε
(	pop
)		pop
*			pop
+				pop
?					pop
\|						pop
other							pop
Z₀								accept

How does an LL1 parser work?

input:

a*b*ε

step: 0

stack:

	(	)	*	+	?	\|	other	ε
→ S	( alt0 ) mod seq alt						other char mod seq alt	ε
alt0	( alt0 ) mod seq alt						other char mod seq alt
alt		ε				\| seq0 alt alt		ε
mod	ε	ε	* star	+ plus	? opt	ε	ε	ε
seq0	( alt0 ) mod seq						other char mod seq
seq	( alt0 ) mod seq seq	ε				ε	other char mod seq seq	ε
terminal	pop	pop	pop	pop	pop	pop	pop
Z₀								accept

reset

How can we represent
the symbols in C++?


							struct S {};
							struct alt0 {};
							struct alt {};
							struct mod {};
							struct seq0 {};
							struct seq {};

							using start_symbol = S;

How can we represent
an LL(1) table in C++?


							// f (symbol, char) → (...)
							auto f(symbol, term<'c'>) -> list{...};

							// f (symbol, symbol) → pop input
							template <auto S> auto f(term<S>, term<S>) -> pop_input;

							// f (symbol, char) → reject
							auto f(...) -> reject;

							// f (Z₀, ε) → accept
							auto f(empty_stack, epsilon) -> accept;

How can we pass
the grammar into the parser?


							struct pcre {
								struct S {};
								struct alt0 {};
								struct alt {};
								// ...

								using start_symbol = S;

								auto f(...) -> reject;
								// ...
							}

How is the parser used?


							constexpr bool ok = parser<pcre, "a+b+">::correct;

How is the parser implemented?


							template <typename Grammar, ...> struct parser {
								//...
								auto next_move = Grammar::f(top_of_stack, current_term);
								//...
							}

How do we implement the input string?


							template <typename CharT, size_t N> struct fixed_string {
								CharT data[N+1];
								// constexpr constructor from const char[N]
								constexpr auto operator[](size_t i) const noexcept { return data[i]; }
								constexpr size_t size() const noexcept { return N; }
								constexpr auto operator<=>(const fixed_string &) = default;
							};

							template <typename CharT, size_t N>
							 fixed_string(const CharT[N]) -> fixed_string<CharT, N>;
							// more info about class NTTP in p0732 by Jeff Snyder and Louis Dionne

How do we implement the stack?


							template <typename... Ts> struct list { };

							template <typename... Ts, typename... As>
							 constexpr auto push(list<Ts...>, As...) -> list<As..., Ts...>;

							template <typename T, typename... As>
							 constexpr auto pop(list<T, Ts...>) -> list<Ts...>;

							template <typename T, typename... Ts>
							 constexpr auto top(list<T, Ts...>) -> T;

							struct empty { };
							constexpr auto top(list<>) -> empty;

How does it fit together?


							constexpr bool ok = parser<pcre, "a*b*">::correct;

LL1 constexpr Parser


							template <typename Grammar, fixed_string Str> struct parser {

								static constexpr bool correct = parse(list<Grammar::start_symbol>{});

								// return current term
								template <size_t Pos> constexpr auto get_character() const {
									if constexpr (Pos < Str.size()) return term<Str[Pos]>{};
									else return epsilon{};
								}

								// prepare each step and move to next
								template <size_t Pos = 0, typename S> static constexpr bool parse(S stack) {

									auto symbol = top(stack);
									auto current_term = get_character<Pos>();

									auto next_move = decltype(Grammar::f(symbol, current_term)){};

									return move<Pos>(next_move, pop(stack));
								}

								// pushing something to stack (epsilon case included)
								template <size_t Pos, typename... Push, typename Stack>
								static constexpr bool move(list<Push...>, Stack stack) {

									return parse<Pos>(push(stack, Push{}...));
								}

								// move to next character
								template <size_t Pos, typename Stack>
								static constexpr bool move(pop_input, Stack stack) {

									return parse<Pos+1>(stack);
								}

								// reject
								template <size_t Pos, typename Stack>
								static constexpr bool move(reject, Stack) {
									return false;
								}

								// accept
								template <size_t Pos, typename Stack>
								static constexpr bool move(accept, Stack) {
									return true;
								}

							};

We need more than
just returning a boolean.

A Pattern to the AST:
Let there be a type

How can we build a type from a string?

Where are the semantic actions placed?

	(	)	*	+	?	\|	other	ε
→ S	( alt0 ) mod seq alt						other char mod seq alt	ε
alt0	( alt0 ) mod seq alt						other char mod seq alt
alt		ε				\| seq0 alt alt		ε
mod	ε	ε	* star	+ plus	? opt	ε	ε	ε
seq0	( alt0 ) mod seq						other char mod seq
seq	( alt0 ) mod concat seq	ε				ε	other char mod concat seq	ε
(	pop
)		pop
*			pop
+				pop
?					pop
\|						pop
other							pop
Z₀								accept

What do the Semantic Action
symbols look like?


							struct pcre {
								struct _char: action {};
								struct alpha: action {};
								struct digit: action {};
								struct seq: action {};
								struct star: action {};
								struct plus: action {};
								struct opt: action {};
								// ...
							}

What are the changes to the parser?


							template <typename Grammar, fixed_string Str> struct parser {

								template <typename Subject>
								static constexpr auto output = parse(list<Grammar::start_symbol>{}, Subject{});

								// return current term
								template <size_t Pos> constexpr auto get_character() const {
									if constexpr (Pos < Str.size()) return term<Str[Pos]>{};
									else return epsilon{};
								}

								// prepare each step and move to next
								template <size_t Pos = 0, typename S, typename T>
								static constexpr auto parse(S stack, T subject) {

									auto symbol = top(stack);

									if constexpr (is_semantic_action(symbol)) {
										auto previous_term = get_character<Pos-1>();

										auto next_subject = decltype( modify(symbol, previous_term, subject) ){};

										return parse<Pos>(pop(stack), next_subject);
									} else {
										auto current_term = get_character<Pos>();
										auto next_move = decltype(Grammar::f(symbol, current_term));

										return move<Pos>(next_move, pop(stack), subject);
									}
								}

								// pushing something to stack (epsilon case included)
								template <size_t Pos, typename... Push, typename Stack, typename Subject>
								static constexpr bool move(list<Push...>, Stack stack, Subject subject) {

									return parse<Pos>(push(stack, Push{}...), subject);
								}

								// move to next character
								template <size_t Pos, typename Stack, typename Subject>
								static constexpr bool move(pop_input, Stack stack, Subject subject) {

									return parse<Pos+1>(stack, subject);
								}

								// reject
								template <size_t Pos, typename Stack, typename Subject>
								static constexpr auto move(reject, Stack, Subject subject) {
									return std::pair{false, subject};
								}

								// accept
								template <size_t Pos, typename Stack>
								static constexpr auto move(accept, Stack, Subject subject) {
									return std::pair{true, subject};
								}

								bool correct = output<list<>{}>.first;

								using type = decltype( output<list<>{}>.second );
							};

What does building from a string look like?

What about the modify function?

Building the AST on a stack


							// pushing a character
							template <Character auto C, typename... Ts>
							 auto modify(pcre::_char, term<C>, list<Ts...>)
							  -> list<ch<C>, Ts...>;

							// concatenating a sequence (notice the switched order of A & B on the stack)
							template <Character auto C, typename A, typename B, typename... Ts>
							 auto modify(pcre::seq, term<C>, list<B, A, Ts...>)
							  -> list<concat<A, B>, Ts...>;

							// adding to a concatenated sequence
							template <Character auto C, typename... As, typename B, typename... Ts>
							 auto modify(pcre::seq, term<C>, list<B, concat<As...>, Ts...>)
							  -> list<concat<As..., B>, Ts...>;

							// making an alternate (again, switched order of A & B)
							template <Character auto C, typename A, typename B, typename... Ts>
							 auto modify(pcre::alt, term<C>, list<B, A, Ts...>)
							  -> list<alt<A, B>, Ts...>;

							// adding to an alternate
							template <auto C, typename... As, typename B, typename... Ts>
							 auto modify(pcre::alt, term<C>, list<B, alt<As...>, Ts...>)
							  -> list<alt<As..., B>, Ts...>;

							// making something optional
							template <Character auto C, typename Opt, typename... Ts>
							 auto modify(pcre::opt, term<C>, list<Opt, Ts...>)
							  -> list<opt<Opt>, Ts...>;

							// making a plus cycle
							template <Character auto C, typename Plus, typename... Ts>
							 auto modify(pcre::plus, term<C>, list<Plus, Ts...>)
							  -> list<plus<Plus>, Ts...>;

							// making a star cycle
							template <Character auto C, typename Star, typename... Ts>
							 auto modify(pcre::star, term<C>, list<Star, Ts...>)
							  -> list<star<Star>, Ts...>;

We have the AST!


						static_assert(std::is_same_v<
							,
							decltype( top(parser<pcre,"">::type) )
						>);

How do we match
a regular expression
in the form of an AST?

Finite Automaton

"And if thou gaze long at a finite automaton,
a finite automaton also gazes into thee."
– Friedrich Nietzsche
(after taking a computer science class)

What's a finite automaton?

(Q, Σ, δ, q₀, F)

a finite set of states Q
a finite set of input symbols (the alphabet) Σ
a transition function δ: Q × Σ →
- P(Q) (nondeterministic FA)
- Q (deterministic FA)
a start state q₀ ∈ Q
a set of accept (final) states F ⊆ Q

A finite automaton accepts exactly the same class of languages as a regular expression.

Example: Integral Numbers
`[0-9]+`

How do you convert
a RegEx into an FA?

∅ (empty set)

There is a direct mapping between
the RE definition and operations over the FAs.

And we need to map it onto C++ code.

How to represent an FA in C++?

(Q, Σ, δ, q₀, F)

a finite set of states Q – set<int> int (implicit)
a finite set of input symbols (the alphabet) Σ – char32_t
a transition function δ: Q × Σ →
- P(Q) (nondeterministic FA) – set<tuple<int, int, char32_t>>
- Q (deterministic FA)
a start state q₀ ∈ Q – int(0)
a set of accept (final) states F ⊆ Q – set<int>

constexpr `fixed_set`


							template <size_t Sz, typename T> class fixed_set {
								T data[Sz];
							public:
								constexpr auto begin();
								constexpr auto end();
								constexpr auto begin() const;
								constexpr auto end() const;

								constexpr size_t size() const;
								constexpr auto & operator[](size_t);
								constexpr const auto & operator[](size_t) const;

								constexpr auto insert(T);

								template <typename K> constexpr auto erase(K);
								constexpr auto erase(T *);

								constexpr set();
								// ...
							};

constexpr `finite_automaton`


							struct transition {
								int source;
								int target;
								char32_t term;

								constexpr transition(int, int, char32_t);
								constexpr bool match(char32_t c) const;
								// comparable with int against source
							};

							template <size_t Tr, size_t FSz> struct finite_automaton {
								fixed_set<Tr, transition> transitions;
								fixed_set<FSz, int> final_states;

								// normal constructor / copy constructor ...
							};

Basic building blocks


								static constexpr auto empty = finite_automaton<0,0>{};

								static constexpr auto epsilon = finite_automaton<0,1>{{}, {0}};

								template <char32_t C> static constexpr auto one_char = finite_automaton<1,1>{
									{transition(0, 1, C)},
									{1}
								};

Concatenation algorithm


							template <finite_automaton Lhs, finite_automaton Rhs> struct concat_two {

								constexpr static auto calculate() {
									constexpr size_t tr_count = Lhs.transitions.size() + Rhs.transitions.size();
									constexpr size_t tr_start = Rhs.count_transitions(0);

									constexpr int prefix = Lhs.get_max_state() + 1;

									finite_automaton<(tr_count + tr_start), Rhs.final_states.count()> out;

									copy(Lhs.transitions.begin(), Lhs.transitions.end(), out.transitions.begin());

									for (int f: Lhs.final_states) {
										Rhs.foreach_transition_from(0, [&](transition t){
											t.source = f;
											t.target += prefix;
											out.add_transition(t);
										});
									}

									for (transition t: Rhs.transitions) {
										t.source += prefix;
										t.target += prefix;
										out.add_transition(t);
									}

									for (int f: Rhs.final_states) out.mark_final(f + prefix);

									return out;
								}

								static constexpr auto value = calculate();
							};

Other algorithms

alternation
repeating (Kleene star)

Both other algorithms work the same,
pre-calculate the size and then populate the content.

Template variable as a "function"


								template <finite_automaton... Fas>
								static constexpr auto concat = apply<concat_two, Fas...>::value;

								template <finite_automaton... Fas>
								static constexpr auto alternation = apply<alternation_two, Fas...>::value;

								template <finite_automaton... Fas>
								static constexpr auto star = star_one<concat<Fas...>>::value;

We have a class-value based
template meta-programming!

And if you use const auto & it's C++17 compatible!

`constexpr auto fa = concat<one_char<'a'>, one_char<'b'>>;`

I called it a "compile time" function with compile-time arguments.
Unlike a constexpr function, it can take constexpr variables as arguments
and maintain their "constexpr-bility".
It makes sure the value is cached.
It looks nice :)

Minimization

Remove unnecessary states and links by merging the same states.

Minimization algorithm

Determinization

Remove nondeterministic transitions, can generate 2ⁿ new states.

Determinization algorithm

Determinization

Remove nondeterministic transitions, can generate 2ⁿ new states.

Constexpr implementation must be iterative,
as the whole output can't be calculated in one step.

It's useful to minimize the FA after the determinization.

We have a deterministic finite automaton

"There is no such thing as a zero-cost abstraction."
– Chandler Carruth

constexpr problems

every operation counts
- there are limits (and different in every compiler)
move semantics don't matter
problematic error handling & debugging
- use a conditional UB or throw-statement as form of an assert
- printf styled debugging
  template <typename T> struct identify_type;

The constexpr problem

sloooooooooow

2 minutes (gcc 9.1)

40 seconds (clang 8)

< 5 second (php 7.1)

(NFA determinization)

Matching
a Regular Expression

"hello" =~ /aloha|[a-z]+/

Matching and searching


							ctre::match<"aloha|[a-z]+">("aloha"sv);

							// search(x) is actually match(.*x.*)
							ctre::search<"aloha|[a-z]+">("...aloha..."sv);

Deterministic match wrapper


							template <fixed_string re> bool fast_match(const Range auto & rng) {
								static_assert(parser<pcre, re>::correct);
								using RE = parser<pcre, re>::type;

								constexpr auto dfa = fa::minimize<fa::determinize<nfa_from<RE>>>;

								return match_state<dfa>(rng.begin(), rng.end());
							}

Converting a RE's AST into an FA


							namespace fa {
								static constexpr auto empty = finite_automaton<0, 0>{};
							}

							template <typename RE>
							static constexpr auto nfa_from = convert(fa::empty, list<RE>{});

RE is a type, finite_automaton is a value.

Converting the empty RE


							auto convert(const FinAutomaton auto seed, list<>) {
								// for an empty RE seed is empty FA

								return seed;

							}

Converting epsilon (empty string)


							namespace fa {
								// epsilon is FA with a start state final
								static constexpr auto epsilon = finite_automaton<0, 1>{{}, {0}};
							}

							template <typename... Ts>
							auto convert(const FinAutomaton auto lhs, list<epsilon, Ts...>) {

								return convert(fa::concat<lhs, fa::epsilon>, list<Ts...>{});

							}

Converting a character


							namespace fa {
								// epsilon is FA with a start state final
								template <char32_t Term> static constexpr auto
								character = finite_automaton<1, 1>{{transition{0, 1, Term}}, {1}};
							}

							template <char32_t Term, typename... Ts>
							auto convert(const FinAutomaton auto lhs, list<character<Term>, Ts...>) {

								return convert(fa::concat<lhs, fa::character<Term>>, list<Ts...>{});

							}

Converting a concat sequence


							template <typename... Content, typename... Ts>
							auto convert(const FinAutomaton auto lhs, list<concat<Content...>, Ts...>) {

								return convert(lhs, list<Content..., Ts...>{});

							}

Converting an alternation


							template <typename... Options, typename... Ts>
							auto convert(const FinAutomaton auto lhs, list<alt<Options...>, Ts...>) {

								constexpr auto inner = fa::alternative<convert(fa::empty, Options)...>;

								return convert(fa::concat<lhs, inner>, list<Ts...>{});

							}

Converting a Kleene star (cycle)


							template <typename Content, typename Ts...>
							auto convert(const FinAutomaton auto seed, list<star<Content>, Ts...>) {

								auto content = convert(fa::empty, Content);

								return convert(fa::concat<lhs, fa::star<content>>, list<Ts...>{});

							}

We have a finite automaton,
now we need to do the matching.

Deterministic match wrapper


							template <fixed_string re> bool fast_match(const Range auto & rng) {
								static_assert(parser<pcre, re>::correct);
								using RE = parser<pcre, re>::type;

								constexpr auto dfa = fa::minimize<fa::determinize<nfa_from<RE>>>;

								return match_state<dfa>(rng.begin(), rng.end());
							}

Matching a state


							template <finite_automaton DFA, int State = 0, typename Iterator>
							constexpr bool match_state(Iterator it, Iterator end) noexcept {

								// we can end correctly only if this state is final
								if constexpr (DFA.is_final(State)) {
									if (end == it) return true;
								} else {
									if (end == it) return false;
								}

								// transitions are sorted by source state
								constexpr auto index = DFA.first_transition_index_of(State);

								// tail-recursion
								return choose_transition<DFA, index, State>(it, end);
							}

Matching a transition


							template <finite_automaton DFA, int Index, int State, typename Iterator>
							constexpr bool choose_transition(Iterator it, const Iterator end) noexcept {
								// check if we are still in same state
								if constexpr (Index >= DFA.transitions.size()
								  || DFA.transitions[Index].source != State) {

									return false;
								}

								if (DFA.transitions[Index].match(*it)) {
									// this transition is the one, go to next state (tail recursion)
									return match_state<DFA, DFA.transitions[Index].target>(std::next(it), end);
								}

								// try next one (also tail recursion)
								return choose_transition<DFA, Index+1, State>(it, end);
							}

The deterministic matching

O(n * t) time complexity
O(1) dynamic memory complexity

n = length of the input, t = average number of transitions per state

doesn't support capture tracking
theoretically the quickest approach
allows streamed data

Other matching algorithms

NFA backtracking (used for captures in CTRE)
NFA without backtracking

Benchmarks

Measurement methodology

grep-like scenario searching in CSV file (1.3GiB) with 6.5 MLoC
Median of 3 measurements
MacBook Pro 13" 2016 i7 3.3Ghz
GCC 9.1 & clang 8 (-std=2a -O3)

Runtime Searching (clang): `[a-z0-9]+[0-9]`

whoo whoo whoo whoo whoo whoo whoo whoo whoo

Measured code (grep-like utility)


							#include <everything>

							int main(int argc, char ** argv) {
								auto re = PREPARE("PATTERN");
								auto lines = load_file_by_lines(argv[1]);

								size_t count = 0;

								// some warm-up

								auto start = steady_clock::now();
								for (string_view line: lines) {
									if (re.SEARCH(line)) count++;
								}
								auto end = steady_clock::now();

								// print results

							}

Compilation (clang): `[a-z0-9]+[0-9]`

whoo whoo whoo whoo whoo whoo

Comparison

Let's read some assembly :)

Five things I showed you…

How regular expression engines work.
Connection between theory and code.
Parsing of a pattern during compilation.
Building of a finite automaton.
Comparison between different regex implementations.

And four things you should remember…

Compilers can optimize your code, if you help them.
Combining TMP and constexpr code can
help you express more things more precisely.
Stop pretending that constexpr C++ is a compiled language.
Try the CTRE library, not just for speed but for code clarity.

Thank you!

You can find slides & code at compile-time.re

A State ofCompile Time Regular Expressions

Hana Dusíková

Hana Dusíková

@hankadusikova

#ctre #cpppfr

std::regex

A story of one std::regex

And it takes only 1.3 sec to compile…

IntroducingThe Compile Time Regular ExpressionsLibrary

A Story of one regex reimagined

Error Reporting

Example: Extracting a value

Example: Iterate overconcatenated sequence of numbers

Example: Unicode Support (🌈🦄🥰)

Example: DFA matching / searching

Features of CTRE

Technical details of CTRE

Regular Expressions

hello|aloha|guten tag|dobrý den|bonjour

[a-z]+[0-9]+

A Regular Expression is (formally)

Non-formal syntax constructs

Example: Non-formal syntax constructs

A Regular Expressioncan be described as an abstract syntax tree

How to store the ASTin C++ compile-time evaluated code?

Types as the building blocks

Example: A Regex Type

ConvertingA pattern into an AST: Parsing

How to convert the pattern?

How does an LL(1) parser work?

What does the grammar look like?

How does an LL1 parser work?

How can we representthe symbols in C++?

How can we representan LL(1) table in C++?

How can we passthe grammar into the parser?

How is the parser used?

How is the parser implemented?

How do we implement the input string?

How do we implement the stack?

How does it fit together?

LL1 constexpr Parser

We need more thanjust returning a boolean.

A Pattern to the AST:Let there be a type

How can we build a type from a string?

Where are the semantic actions placed?

What do the Semantic Actionsymbols look like?

What are the changes to the parser?

What does building from a string look like?

What about the modify function?

Building the AST on a stack

We have the AST!

How do we matcha regular expressionin the form of an AST?

Finite Automaton

What's a finite automaton?

Example: Integral Numbers[0-9]+

How do you converta RegEx into an FA?

∅ (empty set)

There is a direct mapping betweenthe RE definition and operations over the FAs.

How to represent an FA in C++?

constexpr fixed_set

constexpr finite_automaton

Basic building blocks

Concatenation algorithm

Concatenation algorithm

Other algorithms

Template variable as a "function"

We have a class-value basedtemplate meta-programming!

constexpr auto fa = concat<one_char<'a'>, one_char<'b'>>;

Minimization

Minimization algorithm

Determinization

Determinization algorithm

Determinization

We have a deterministic finite automaton

constexpr problems

The constexpr problem

Matchinga Regular Expression

Matching and searching

Deterministic match wrapper

Converting a RE's AST into an FA

A State of
Compile Time Regular Expressions

`std::regex`

A story of one `std::regex`

Introducing
The Compile Time Regular Expressions
Library

Example: Iterate over
concatenated sequence of numbers

`hello|aloha|guten tag|dobrý den|bonjour`

`[a-z]+[0-9]+`

A Regular Expression
can be described as an abstract syntax tree

How to store the AST
in C++ compile-time evaluated code?

Converting
A pattern into an AST: Parsing

How can we represent
the symbols in C++?

How can we represent
an LL(1) table in C++?

How can we pass
the grammar into the parser?

We need more than
just returning a boolean.

A Pattern to the AST:
Let there be a type

What do the Semantic Action
symbols look like?

How do we match
a regular expression
in the form of an AST?

Example: Integral Numbers
`[0-9]+`

How do you convert
a RegEx into an FA?

There is a direct mapping between
the RE definition and operations over the FAs.

constexpr `fixed_set`

constexpr `finite_automaton`

We have a class-value based
template meta-programming!

`constexpr auto fa = concat<one_char<'a'>, one_char<'b'>>;`

Matching
a Regular Expression

We have a finite automaton,
now we need to do the matching.

Runtime Searching (clang): `[a-z0-9]+[0-9]`

Compilation (clang): `[a-z0-9]+[0-9]`
